Allied Cardiagard II Semi‑Automatic Defibrillator with 5" LCD Screen

New

4.5

12456 Ratings

Specifications

Physical Dimensions : H (232mm) × W (209mm) × D (59mm)
Weight : 1.5 kg (including battery, pads & handle)
Display : 5" Colored LCD Screen
Resolution : 800 × 480
Impact Resistance : Withstands 1.5m drop onto hard surface
Operating Temperature : 0°C to +50°C
Extreme Cold Operation : –20°C for one hour
Storage/Transport Temp : –40°C to +70°C (within one week, battery & pads uninstalled)
Atmospheric Pressure : 59.4 kPa to 106 kPa
Relative Humidity : 5% to 95% (non-condensing)
Ingress Protection : IP55
Battery Type : Lithium Manganese Dioxide (Li/MnO₂), 12V/3000mAh
Battery Capacity : 200±10 shocks at 150J (at 20°C±2°C)
Standby Battery Life : 5 years (typical)
Low Battery Functionality : Delivers 30 shocks at 150J after low battery indication
Data Storage Capacity : ≥8 hours of ECG/event data; self-test data for 10 years
Defibrillation Waveform : Bi-phasic Truncated Exponential (BTE)
Impedance Range : 20–180Ω
Energy Output : 150J for adults; 50J for children at 50Ω impedance
CPR Coaching : Metronome, voice guidance, hand placement, child-specific CPR instructions
CPR Protocol : AHA 2020 compliant
Charge/Discharge Time : 7 seconds (from “Shock Advised” prompt)
Device Indicators : Visual & audible; flashing green = normal, red = fault
Controls : Semi-automatic; child mode button; bilingual language selection (Cardiagard–II)
Communication Interfaces : USB, Bluetooth
Pads : Compatible for adult and child use
Pad Shelf Life : 4 years from manufacturing
Pad Cable Length : 1.1 ± 0.1 m
Pad Storage : Integrated compartment at back of device
Arrhythmia Analysis Accuracy : IEC 60601-2-4 compliant
Analysis Time : Typically 8 seconds

highlights

Shock control semi-automatic
Screen size 5″ LCD screen
Animation, voice and bilingual text prompts.
ECG/event storage at least 8 hours of ECG and event/incident recording
Language Button : Users can switch between primary and secondary language among various available language options.
Self-test data storage Up to 10 years
Communication USB interface, bluetooth (standard); 4G module (optional)

Use Cases :

Public access defibrillation in high-traffic areas (e.g., airports, shopping malls, sports stadiums)
Emergency response in healthcare facilities (hospitals, clinics)
Workplace safety and emergency preparedness
Educational institutions and community centers
Ambulances and emergency medical services

Key Features :

5” Colored LCD Display with animation and bilingual text support
Semi-automatic operation with shock and child mode buttons
Real-time CPR coaching compliant with AHA 2020 guidelines
Durable build with IP55 rating and 1.5m drop resistance
Long-lasting lithium battery with up to 200 shocks at 150J
USB and Bluetooth connectivity for data retrieval
Integrated storage for pads with adult/child compatibility
Self-test memory retention up to 10 years

Warranty

Seller

AA MEDIE QUIPLearn More

Product Description

The ALLIED CARDIAGARD-II AED is a highly advanced and user-friendly Automated External Defibrillator designed for public access use during emergencies. Equipped with a 5" colored LCD screen and intuitive voice and text prompts, this semi-automatic device provides real-time CPR coaching and delivers ...
